Name: UV Photolysis
Brand: ONYX
Author: ONYX Technical Team

Advantages

The reaction pathway is simple, with no additional reagent costs.
No waste generation (no secondary pollution)
Achieve treatment requirements in a very short time
High reliability, enabling automatic control and remote monitoring, eliminating the need for on-site staff
The UV reactor is modular, pre-assembled, and easily replaceable
No odor or foul-smelling gases are generated after treatment

Parameter

Product Series	ONYX-EX-UPW-TOC	ONYX-Clear	ONYX-Extrem
Application	Ultrapure water TOC removal	Residual chlorine removal and disinfection before RO membrane of purified water	Decomposition and disinfection of ammonium chloride in swimming pools and water features
Inlet and outlet sizes	DN50-DN200	DN100-DN600	DN80-DN200
Lamp type	Low pressure lamps	Medium pressure lamps	Medium pressure lamps
Lamp life	12000h	9000h	9000h
Single lamp power	85w、155w（185, 254nm dual band）	1~12KW	1~3KW
Lamp power adjustment range	50-100%	50-100%	50-100%
Shell material	Stainless steel 316L	Stainless steel 304/316L	Stainless steel 316L
Cleaning drive system	/	Motor Drive	Motor Drive
Automatic Cleaning	/	Online Automatic Mechanical Cleaning	Online Automatic Mechanical Cleaning
UV intensity sensor	1 per device	1 per device	1 per device
Temperature sensor	1 per device	1 per device	1 per device
Installation location	Indoor	Indoor	Indoor
Control Cabinet Protection Level	IP54	IP54	IP54
Control System	Touch screen + PLC control	Touch screen + PLC control	Touch screen + PLC control
Power specifications	220V/50HZ	220V/50HZ	220V/50HZ
Head loss	＜400mm	＜400mm	＜400mm

Technical Specifications

Parameter	Specification
Model	UV Photolysis
Treatment Capacity	Customized, range 1 - 100,000 m3/day
UV Dose	≥40 mJ/cm2 (meets NSF/EPA standards)
Lamp Type	Low-pressure high-output / Medium-pressure (optional)
Effective Lamp Lifespan	12,000 - 17,000 hours
Reactor Material	316L Stainless Steel / 304 Stainless Steel
Operating Temperature	5 - 45 °C
IP Rating	IP68 (lamp module) / IP65 (control cabinet)
Cleaning Method	Automatic mechanical cleaning / Chemical cleaning (optional)
Control System	PLC automatic control, SCADA remote monitoring supported
Certification	CE, NSF/ANSI 55, GB/T 19837

Application Scenarios

UV Photolysis is widely used in the following applications:

Municipal Water & Wastewater: Drinking water plant disinfection, wastewater effluent treatment, water reuse disinfection
Industrial Water Treatment: Electronics ultrapure water, pharmaceutical water, food and beverage processing water
Marine & Shipping: Ballast water treatment, onboard sewage treatment
Aquaculture: Recirculating aquaculture system (RAS) water disinfection, hatchery water treatment
Swimming Pools & Landscapes: Pool water disinfection, ornamental water circulation
Advanced Oxidation: UV-AOP process for degrading refractory organics and removing micropollutants

Technical Principle

UV disinfection technology utilizes ultraviolet light (wavelength 254nm) to damage the DNA/RNA structure of microorganisms, rendering them unable to reproduce and effectively sterilizing the water. Compared with chemical disinfection, UV treatment requires no chemical additives, produces no disinfection by-products (DBPs), achieves high inactivation efficiency against bacteria, viruses, and spores, and requires only seconds of contact time. It is a safe, environmentally friendly physical disinfection method.

ONYX UV equipment features optimized reactor hydraulic design ensuring uniform UV dose distribution, paired with an automatic cleaning system to maintain lamp transmittance for long-term stable operation. The equipment supports online UV dose monitoring and real-time operational status feedback, and can be seamlessly integrated into existing SCADA systems.
