Aquaculture

High-density aquaculture models are prone to huge economic losses due to water quality deterioration and the breeding of pathogenic microorganisms.


Ultraviolet (UV) disinfection technology, a proven physical disinfection method, is widely used in aquaculture to eliminate viruses and microorganisms in water. Both large-scale recirculating aquaculture systems and small-scale hatcheries require UV disinfection processes:

· Recirculating Aquaculture Systems (RAS): RAS systems use a water recirculation treatment system to conserve water resources and control the aquaculture environment. UV disinfection devices are typically installed after physical and biological filtration to eliminate pathogens that may accumulate in the circulating water, preventing disease outbreaks and spread within the system.

· Water Treatment in Hatcheries and Hatcheries: The early life stages of fish, shrimp, crab, and shellfish are extremely sensitive to pathogens. UV disinfection can be used to treat raw or recirculating water entering hatchery ponds or hatchery tanks, significantly reducing the total number of pathogens and improving hatchery survival rates.

Ozone Destruction: In RAS systems that also utilize ozone oxidation, UV light (at a specific wavelength) can also be used to decompose residual ozone in the water, preventing its toxicity to aquaculture organisms.

The effectiveness of UV disinfection depends primarily on the UV dose:

UV dose (UVDose) is the most critical parameter determining disinfection effectiveness. Different farmed fish species are susceptible to different pathogens, and different microorganisms are effectively inactivated by UV radiation, requiring specific doses.


Applications of Ozone Disinfection Technology in Aquaculture:

Ozone (O3) is a strong oxidant that effectively oxidizes and decomposes dissolved organic matter (DOM) in water, such as organic acids and humus produced by the decomposition of leftover bait and feces. Ozone can partially oxidize ammonia nitrogen (NH3/NH4+) and nitrite (NO2-), which are toxic to aquaculture organisms, into less toxic nitrate (NO-). It can also oxidize and remove harmful gases such as hydrogen sulfide (H2S).

One of the end products of ozone decomposition in water is oxygen, which can effectively increase the dissolved oxygen content in the water and improve the living environment for aquaculture organisms.

Ozone treatment can reduce or even replace the use of some traditional disinfectants and antibiotics, reducing the risk of drug residues and contributing to the production of green aquatic products.

Application Scenarios of Ozone Technology in Aquaculture:

Industrial Recirculating Aquaculture Systems (RAS):

· Nursery and juvenile rearing

· Improving feed conversion and promoting growth

· Temporary holding and purification of seafood

UV-Ozone Synergistic AOPS Process:

The core of the UV/ozone synergy lies in the catalytic decomposition of ozone by UV light. When UV light of a specific wavelength (typically 254nm) is irradiated into water containing ozone, ozone molecules absorb the UV energy and decompose, producing a series of highly reactive intermediates. The most important is the highly oxidizing hydroxyl radical (·OH), a non-selective, strong oxidant.

Application Scenarios:

High-density, high-standard industrial recirculating aquaculture systems (RAS) are nursery and seed preservation systems with extremely high water quality and biosafety requirements.


Previous
High-quality drinking water POE/POU

Next
Cooling Circulating water

Related Products

D.FITE Cloth Filter

D.FITE Cloth Filter

The ONYX-D.FITE cloth filter series is suitable for installation in civil engineering water tanks.

This fine filtration technology, developed based on fiber filter cloth, boasts high filtration accuracy, excellent filtration performance, minimal auxiliary equipment, and low head loss. Its advantages include high filtration precision, excellent filtration efficiency, minimal auxiliary equipment, and low head loss. It is widely used in wastewater advanced treatment, circulating water filtration, and pre-treatment for advanced treatment processes.

The external-inlet, internal-outlet fiber disc filter consists of a series of horizontally mounted rotating filter discs fitted with easily removable filter cloths with a pore size of 10 μm.

The fiber disc filter operates in various modes: filtration, backwashing, and sludge removal.

 EX-U UV Sterilizer

EX-U UV Sterilizer

The ONYX-EX-SUe series features a pipeline-type design with inlet and outlet flange connections, constructed from high-strength, corrosion-resistant 304/316L stainless steel. The control cabinet is integrated with the equipment housing, eliminating the need for a separate cabinet bracket. This makes installation easy and space-saving.

The ONYX-EX-SUe incorporates innovative technologies, including integrated design, food-grade processing, automatic mechanical cleaning, and CFD flow simulation, to reduce costs and significantly simplify operation and maintenance.

The ballast, operating indicator, timer, alarm, and intelligent control system are all integrated within the control cabinet. The system offers strong sterilization performance, long life, and stable operation. Its sterilization efficiency is ≥99.9%, and its lamp life is ≥12,000 hours.

 MOM Ceramic Plate CD Ozone Generator

MOM Ceramic Plate CD Ozone Generator

The MOM series of large ozone generators feature a highly efficient plate-type ozone generation system, a simple, high-end modular assembly design, a stable power supply system discharge module, a uniform discharge module cooling unit, sophisticated porcelain dielectric processing, and convenient construction and installation to ensure optimal ozone concentration and efficiency. These devices offer low energy consumption, high concentration, high power density, high reliability, ease of use, and intelligent functionality. They are widely used in drinking water treatment, reclaimed water and wastewater treatment, aquaculture and aquatic product processing, swimming pool disinfection, industrial oxidative bleaching, and landfill leachate treatment.

 CLEAR Medium pressure UV Disinfection System

CLEAR Medium pressure UV Disinfection System

The ONYX-Clear-SY in-line medium-pressure UV sterilizer uses medium-pressure UV lamps for physical sterilization, without the addition of any chemicals or secondary pollution. It offers safe operation, ease of use, and reduced operating costs and maintenance.

The treated water does not affect taste or flavor. It complies with water standards such as the Food Safety Law of the People's Republic of China, the Sanitary Standard for Drinking Water (GB 5749), the Drinking Water Quality Standard (CJ94-2005), the National Food Safety Standard for Drinking Natural Mineral Water (GB 8537-2018), and the Packaged Drinking Water Standard (DGB19298-2014).
